Grain moisture meter SUPERTECH FarmPoint
Purpose and scope:
Grain moisture meter SUPERTECH FarmPointis designed for express control of the moisture content of grain and seeds of agricultural crops.
Grain crops: corn, wheat, rye, barley, oats, buckwheat, rice, sorghum, millet, red fescue, meadow fescue.
Legumes: peas, soybeans, clover.
Oilseeds: sunflower, rapeseed, flax,
Description:
This is a handy, portable electronic device in which moisture content readings are displayed as a percentage on an electronic display. Uses dielcometric principle of measurement.
Principle of operation: after the passage of a high frequency voltage through the grain, a gradual decrease in the intensity of the electric current occurs. The operation of the meter is based on the indicators of voltage drop, the device examines the moisture content of the sample and displays the result on the display.
Ability to adjust the factory calibration for each measured crop allows you to customize the device for specific samples and get a more accurate result.
Specifications
| Model | FarmPoint | FarmPro | SuperPoint | SuperPro |
| Type | portable | portable | portable | portable |
| Measurement type | dielcometric | resistive | dielcometric | resistive |
| Sample preparation | without grinding | with grinding | without grinding | with grinding |
| Number of calibrations | 19 | 19 | 20 | 20 |
| Measurement range, % | 5…45 | 5…50 | 5…45 | 5…50 |
| Permissible values of absolute measurement error: | ||||
| – in the range up to 18-20%; %, not more | ±0,5 | ±0,3 | ±0,5 | ±0,3 |
| – in the range of more than 18-20%; %, not more | ±1,0 | ±0,5 | ±1,0 | ±0,5 |
| Power supply | battery, 9V | battery, 9V | battery, 9V | battery, 9V |
| Overall dimensions L × W × H, mm | 210 х 75 х 100 | 210 х 75 х 100 | 210 х 80 х 130 | 210 х 80 х 130 |
| Weight without/with case, kg | 0,6 / 1,5 | 0,95 / 2,0 | 0,6 / 1,5 | 0,95 / 2,0 |
Аdvantages
1. Shockproof plastic case;
2. Display backlight;
3. Built-in measuring containers for sampling;
4. Display of humidity readings to the nearest tenth;
5. Automatic temperature compensation;
6. Automatic averaging of several measurements;
7. Automatic power off;
8. Individual adjustment of factory calibrations;
9. Compression of the measured sample in the measuring cylinder;
10. Crushing of the sample in the measuring cylinder;
11. Millstone and press mounted in the measuring chamber;
12. The housing is made of impact-resistant ABS plastic;
13. Millstones are made of hardened steel.
