Groats plansifter RKO-4
Self-balancing plansifter RKO-4 is designed for selection of intermediate products of hulling and grinding, sorting and control of products at enterprises of groats industry.
Product video
Product Description
Specifications
Аdvantages
Video/Photo
Additional Information
Описание
Описание
Олис
Олис
Self-balancing plansifter RKO-4 is designed for selection of intermediate products of hulling and grinding, sorting and control of products at enterprises of groats industry.
The principle of plansifter RKO-4 operation consists in parallel and sequential sieving of the product through a set of flat horizontal sieves that perform a circular translational motion. The initial product, by means of gravity transport, enters the receiving box, where it is separated into sieve frames.
Specifications
Выберите модель
| Model | RKO-4 |
| Rated pre-installed power, kW | 3,0 |
| Frequency of circular vibrations of the body, s-1 (rpm) | 160 |
| Radius of circular vibrations of the body, mm | 35 |
| Sifting surface area, m2 | up to 20 |
| Number of frames in a section, pcs. | up to 20 |
| Number of sections, pcs. | 4 |
| Weight, kg | 1000 |
| Overall dimensions, mm length width height |
1750 1750 2300 |
Аdvantages
- Lack of dynamic loads on the floor;
- Weight of the plansifter in running order is two to three times less than that of analogues;
- The body of the plansifter and sieve frames is made of aluminum and stainless steel, which meets modern sanitary and epidemiological requirements;
- Hermetic manufacturing does not require aspiration;
- No contaminations;
- Convenience and ease of replacement of sieves, which ensures minimal time spent when switching to other numbers of sieves;
- Highly efficient sieve cleaning, allowing the use of the entire sifting surface;
- Components from leading European manufacturers are used;
- The use of modern materials that can significantly increase the service life of the plansifter;
- Possibility of installation of sieving in premises with a height of 2.5 m.
Photos
Выберите модель
| Model | RKO-4 |
| Rated pre-installed power, kW | 3,0 |
| Frequency of circular vibrations of the body, s-1 (rpm) | 160 |
| Radius of circular vibrations of the body, mm | 35 |
| Sifting surface area, m2 | up to 20 |
| Number of frames in a section, pcs. | up to 20 |
| Number of sections, pcs. | 4 |
| Weight, kg | 1000 |
| Overall dimensions, mm length width height |
1750 1750 2300 |
- Lack of dynamic loads on the floor;
- Weight of the plansifter in running order is two to three times less than that of analogues;
- The body of the plansifter and sieve frames is made of aluminum and stainless steel, which meets modern sanitary and epidemiological requirements;
- Hermetic manufacturing does not require aspiration;
- No contaminations;
- Convenience and ease of replacement of sieves, which ensures minimal time spent when switching to other numbers of sieves;
- Highly efficient sieve cleaning, allowing the use of the entire sifting surface;
- Components from leading European manufacturers are used;
- The use of modern materials that can significantly increase the service life of the plansifter;
- Possibility of installation of sieving in premises with a height of 2.5 m.
