Flour plansifter RMO-4
Self-balancing plansifter RMO-4 is designed for sorting into fractions depending on size of milling products of wheat grain in mill enterprises for high-grade grinding. The plansifter can be used for sorting into fractions of grinding grain products of other cultures.
Product Description
Specifications
Аdvantages
Video/Photo
Additional Information
Описание
Описание
Олис
Олис
Self-balancing plansifter RMO-4 is designed for sorting into fractions depending on size of milling products of wheat grain in mill enterprises for high-grade grinding. The plansifter can be used for sorting into fractions of grinding grain products of other cultures.
The principle of sifting consists in parallel and sequential sieving of the product through a set of flat horizontal sieves that performs a circular translational movement. The initial product from the receiving boxes enters the feeders, from where, being distributed into three streams, it is directed to the sieve frames of the body, with the help of which the sorting process occurs.
Plansifter offered by Olis will be a good acquisition for your business.
Specifications
Выберите модель
| Model | RMO-4 |
| Rated installed power, kW | 3,0 |
| Frequency of circular vibrations of the body, s-1 (fluctuations/min) | 240 |
| Radius of circular vibrations of the body, mm | 35 |
| Sifting surface area, m2 | up to 22 |
| Number of frames in a section, pcs. | up to 22 |
| Number of sections, pcs. | 4 |
| Weight, kg | 1000 |
| Overall dimensions, mm length width height |
1750 1750 2500 |
Аdvantages
- Lack of dynamic loads on the floor;
- Weight of the plansifter in running order is two to three times less than that of analogues;
- The body of the plansifter and sieve frames is made of aluminum and stainless steel, which meets modern sanitary and epidemiological requirements;
- Hermetic manufacturing does not require aspiration;
- No contaminations;
- Convenience and ease of replacement of sieves, which ensures minimal time spent when switching to other numbers of sieves;
- Highly efficient sieve cleaning, allowing the use of the entire sifting surface;
- Components from leading European manufacturers are used;
- Use of modern materials that can significantly increase the service life of the plansifter;
- Possibility of installation of sieving in premises with a height of 2.5 m.
Video
Выберите модель
| Model | RMO-4 |
| Rated installed power, kW | 3,0 |
| Frequency of circular vibrations of the body, s-1 (fluctuations/min) | 240 |
| Radius of circular vibrations of the body, mm | 35 |
| Sifting surface area, m2 | up to 22 |
| Number of frames in a section, pcs. | up to 22 |
| Number of sections, pcs. | 4 |
| Weight, kg | 1000 |
| Overall dimensions, mm length width height |
1750 1750 2500 |
- Lack of dynamic loads on the floor;
- Weight of the plansifter in running order is two to three times less than that of analogues;
- The body of the plansifter and sieve frames is made of aluminum and stainless steel, which meets modern sanitary and epidemiological requirements;
- Hermetic manufacturing does not require aspiration;
- No contaminations;
- Convenience and ease of replacement of sieves, which ensures minimal time spent when switching to other numbers of sieves;
- Highly efficient sieve cleaning, allowing the use of the entire sifting surface;
- Components from leading European manufacturers are used;
- Use of modern materials that can significantly increase the service life of the plansifter;
- Possibility of installation of sieving in premises with a height of 2.5 m.
