Aspiration channel AK
Aspiration channel AK is designed to separate impurities from grain, hulling products of groats crops, which differ in aerodynamic properties. It is used in technological lines of groats and flour mills.
Product Description
Specifications
Аdvantages
Video/Photo
Additional Information
Описание
Описание
Олис
Олис
Purpose and scope of application:
Aspiration channel AK is designed to separate impurities from grain, hulling products of groats crops, which differ in aerodynamic properties. It is used in technological lines of groats and flour mills.
Description:
The column consists of a body in which a number of partitions are installed. The product enters the aspiration column through the inlet pipe and, passing through the partitions, is blown by air, which removes light impurities into the aspiration system. It can be equipped with a bag clamping device when using the machine for groats packaging.
Specifications
Выберите модель
| Model | АК-100 | АК-120 | АК-200 | АК-300 |
| Productivity up to kg/h of grain of hulling products of groats |
— 400-500 200-300 |
— 600-800 350-500 |
1300-2000 800-1000 400-600 |
2000-3000 1500-2000 800-1000 |
| Air consumption for aspiration, m3/h | 150 | 250 | 300 | 450 |
| Efficiency, % for grain for peeling products for groats |
— 80 95-97 |
— 80 95-97 |
75 80 95-97 |
75-80 85-90 95-97 |
| Weight, kg | 10 | 11 | 12 | 20 |
| Overall dimensions, mm length width height |
310 100 465 |
340 120 605 |
355 200 970 |
355 300 970 |
Аdvantages
- Rational design, small dimensions;
- Convenience and smoothness of adjustment;
- Convenience of visual control of the aspiration chamber, which allows you to optimally adjust the process;
- Improved cleaning efficiency.
